MBGP/DVMRP usage: stacked by protocol.
Key:
Red, green and blue represent forwarding cache entries that have
been used to forward packets; other colors represent
those that have not been used to forward any packets.
The areas are "stacked", meaning that the actual value is the
height of the shaded area, not the value of the top of the area.
- green
- Entries for protocols other than DVMRP and MBGP that have been used to forward packets.
- yellow
- Entries for protocols other than DVMRP and MBGP that have not been used to forward packets.
- blue
- Entries for DVMRP that have been used to forward packets.
- magenta
- Entries for DVMRP that have not been used to forward packets.
- red
- Entries for MBGP that have been used to forward packets.
- cyan
- Entries for MBGP that have not been used to forward packets.
