MBGP/DVMRP usage: stacked, just real.

Key:

The areas represent forwarding cache entries that have been used to forward packets. The areas are "stacked", meaning that e.g. the actual number of MBGP entries that have been used to forward any packets is the height of the red area starting at the top of the blue area.

Note that this is the same as graph #1, without the 0-forward entries.

green

Protocols other than DVMRP and MBGP.

blue

DVMRP

red

MBGP
